The CD 9 remote control, included with your C 568 Compact Disc Player, allows you to operate playback functions from the comfort of your chair or anywhere in the room. For reliable operation, ensure there is a clear line-of-sight path from the remote control to the front of the CD player. If the player does not respond to remote commands, the line of sight may be obstructed by clothing, paper, or furnishings.
Most buttons on the remote control have the same functions as the corresponding buttons on the player's front panel. Additionally, the remote is equipped with some extra function keys.
| 1 | ON | Switch ON C 568. |
| 2 | OFF | Switch OFF C 568. |
|
3 |
CD | Select CD as the active source. |
| USB | Select USB as the active source. | |
| OPT | Select optical input as the active source. *Not applicable for C 568. |
|
| SRC | Toggle to select the desired SRC mode. *Not applicable for C 568. |
|
| 4 | RAND | Play tracks/files in random mode. |
| RPT | Repeat track, file, or whole disc. | |
| RPT A-B | Setup repeat sequence. | |
|
5 |
DISP | Show playback time and other display information. |
| PROG | Enter or exit program mode. | |
| CLEAR | Delete programmed track/file | |
| 6 | FILTER | Select the filter number. |
|
7 |
FOLDER [⯊/⯋] | Select through folder lists. |
| FILE [◖/◗] | Select through WMA/MP3 files. | |
| ENTER | Select the desired folder or WMA/MP3 file. | |
| 8 | DIM | Reduce, turn off, or restore VFD brightness |
| 9 | STOP [⏹] | Stop playback |
| 10 | ⏸ | Pause playback temporarily |
| 11 | OPEN [⏏] | Open or close the disc tray. |
|
12 |
SKIP [⏭] | Go to the next track or file. |
| SKIP [⏮] | Go to the beginning of the current track/file or to the previous track/file. | |
| SCAN [⏪/⏩] | Fast reverse/forward search. | |
| [⏵] | Start playback. | |
| 13 | 0 to 9 NUMBER BUTTONS | Direct entry of track or file number. |
REPEAT [RPT]
You can repeat a specific track or file by pressing the [RPT] button.
- Toggle this button to cycle through repeat modes: repeat a track/file, repeat a folder, or repeat all tracks/files. The corresponding icons (REPEAT, REPEAT FOLDER, or REPEAT ALL) will be illuminated on the FRONT PANEL DISPLAY (VFD) to indicate the selected mode.
- To turn off repeat mode, press the [RPT] button until the REPEAT icon is no longer displayed on the VFD.
REPEAT A-B [RPT A-B]
To repeat a sequence, follow these steps:
1. Press [RPT A-B] at your chosen starting point. "REPEAT A B" will illuminate on the VFD, with "B" blinking.
2. Press [RPT A-B] again at your chosen end point. "REPEAT A B" will stay illuminated, and the repeat sequence will begin.
3. Press [RPT A-B] again to cancel the sequence.
DIM
Toggle to reduce, turn off, and restore the front panel display (VFD) brightness.
Number buttons 0 - 9
Using the direct-entry numeric keypad (0 to 9) on the C 568 allows you to jump directly to the beginning of a specific track or file and start playback. For example, to play Track 5, simply press "5." To play File 20, press "2" followed by "0."
